Every television relies on a steady and carefully regulated flow of power to operate correctly. The component responsible for managing that power is the power supply board, sometimes referred to as the PSU or power board. Its job is to take the high voltage electricity from your wall outlet and convert it into the lower voltages required by the TV’s internal circuits. Because nearly every system inside the TV depends on this board, power related failures are some of the most common issues we see at TVpartsToday.
Below is an example of a power supply board from a Samsung TV:
Before working around a power supply board, safety should always come first. These boards can retain voltage even after the TV is unplugged, so caution and patience are essential. Again, REMEMBER TO ALWAYS USE CAUTION WHEN HANDLING POWER SUPPLY BOARDS! Prioritize safety as you proceed.
If you prefer a visual introduction to TV repair basics, our How To Get Started video on YouTube walks through what to expect before opening your set. You can watch it below:
Below is a video showcasing a power supply board swap in an LG brand TV, in case you'd like a visual example of that as well:
How the Power Supply Board Powers the TV
The power supply board performs several critical tasks at once. First, it converts alternating current from your home outlet into direct current that the TV can safely use. Different parts of the television require different voltage levels, so the power board produces multiple outputs such as five volts, twelve volts, and twenty four volts depending on the model.
Once those voltages are created, the board regulates and distributes them throughout the TV. This regulation protects sensitive components from voltage spikes or drops that could cause damage. The main board, T Con board, audio circuits, and display drivers all depend on stable output from the power supply to function properly.
Another key role of the power supply board is managing standby and startup power. Even when the TV appears off, a small standby voltage remains active so the set can respond instantly to the remote. When you press the power button, the main board signals the power supply to activate the remaining voltage rails and bring the TV fully online.
Understanding the Difference Between a Power Supply and an LED Driver
Although closely related, the power supply board and LED driver do not always perform the same job. The power supply creates and distributes general system voltage, while the LED driver controls the high voltage current needed to illuminate the LED backlights behind the screen.
In many modern LED and LCD televisions, the LED driver circuitry is built directly into the power supply board. In these designs, a single board handles both general power distribution and backlight control. You may see dedicated connectors on the power board that lead directly to the LED strips inside the panel.
Some larger or premium TVs use a separate LED driver board. In those cases, the power supply sends a standard voltage to the LED driver, which then boosts and regulates it to safely power the backlights. Knowing whether your TV uses an integrated or separate LED driver is important when ordering replacement parts.
Symptoms That Point to a Power Supply Board Problem
A failing power supply board can produce a wide range of symptoms. A TV that will not turn on at all or shows no standby light often indicates a loss of standby voltage. Clicking sounds with no picture or sound can signal that the main voltage rails are failing to engage. Random shutdowns are frequently caused by overheating or aging capacitors that can no longer regulate voltage correctly.
When a TV has sound but no picture, the LED driver section of the power supply is often involved, especially in models where the driver is integrated into the power board. In these cases, a single board replacement can restore both power stability and backlight function.
Diagnosing and Replacing a Power Supply Board
Initial diagnosis often starts with a visual inspection. Bulging capacitors, burn marks, or a blown fuse are strong indicators that the power supply has failed. For those experienced with electronics, voltage testing using a multimeter can confirm whether standby and operating voltages are present. This step should only be performed if you are comfortable working around high voltage components.
Replacing a power supply board is usually straightforward. These boards are modular and secured with screws and connectors rather than soldered connections. When ordering a replacement, matching the exact part number is critical. TVs with the same model number can use different power boards depending on production run or region, and this becomes even more important if the LED driver is integrated into the board.
The power supply board is one of the most important components inside a television, providing the foundation that allows every other system to operate. When power issues appear, understanding how this board works makes diagnosis far more accurate and prevents unnecessary part replacements. Whether your TV has no power, shuts down unexpectedly, or has a black screen with sound, the power supply board or its LED driver section is often the root cause. TVpartsToday is here to help you identify the correct part number and complete your repair safely and confidently.
