A Printed Circuit Board (PCB) is the backbone of almost every modern electronic device. It’s the flat, typically green (but sometimes blue, black, tan, or even red!) board that holds and connects all the other electronic components. Think of it like the highway system that keeps your TV’s “electronic traffic” flowing.
PCBs serve two essential roles:
-
🧱 Physical Support – They provide a solid platform to hold and organize components like chips, resistors, capacitors, and connectors.
-
⚡ Electrical Connectivity – Using thin copper traces etched into the board, they route electrical signals from one part to another with precision and speed.
📐 Construction Details:
All PCBs are made from alternating layers of copper (conductive) and insulating material. After layers are etched, laminated, and drilled, they’re topped with:
-
Solder Mask: A protective non-conductive coating (usually green).
-
Silk Screen: Printed legends (white text/labels) that identify components.
Once the board is finished, it heads to PCBA (Printed Circuit Board Assembly), where electronic components are soldered into place - turning a simple board into a fully functioning part!
📺 What Does That Have to Do with My TV?
In TVs, PCBs are everywhere. They are the reason your screen lights up, your HDMI inputs work, and your apps stream Netflix without a hitch. When you're troubleshooting or replacing a board, you're dealing with a specific type of PCBA, each with its own responsibilities.
Here are the most common PCBAs you'll find inside your television:
🔧 Main Board (Motherboard)
-
🧠 The TV’s brain.
-
Manages HDMI/USB inputs, smart TV features, and menu systems.
-
Sometimes includes integrated Wi-Fi or T-con functionality.
⚡ Power Supply Board
-
Converts the electricity from your wall into usable voltages for the TV’s internals.
-
May also include the LED driver on some models.
🖼️ T-Con (Timing Control) Board
-
Controls pixel timing and image rendering.
-
Sends data from the main board to the LCD panel.
📶 Wi-Fi Board (on select smart TVs)
-
Handles wireless connectivity.
-
Often integrated into the main board on newer models.
💡 LED Driver Board
-
Provides power and timing signals to the backlights.
-
Sometimes integrated into the power supply board.
TVpartsToday Tip: When you're replacing any of these boards, ALWAYS order using the part number, not the board number printed directly on the PCB! Board numbers often reference the raw board design, not the specific configuration your TV needs.
🔍 Want to Learn More?
These boards are the most likely candidates when troubleshooting and repairing your TV. Want to dig deeper into each one? We’ve got dedicated blog articles that break down each board’s role, symptoms of failure, and how to replace them:
🧠 Final Thoughts: What You’re Really Working With
Understanding PCBs is the first step to becoming a confident DIY TV repair pro. These boards are more than just plastic and copper—they’re the central nervous system of your TV, and knowing what they do (and how to replace them!) can save you serious time and money.
Whether you're replacing a power board, main board, or a T-con, always check the part number carefully and reach out to us if you’re unsure. Our team at TVpartsToday is here to help you every step of the way.
