8 Common Mistakes Made When Replacing TV Parts (And How to Avoid Them)

8 Common Mistakes Made When Replacing TV Parts (And How to Avoid Them)

Mike Smith |

So your TV stopped working and you're ready to roll up your sleeves and fix it yourself - we love to see it! đź’Ş

But before you grab a screwdriver or start shopping for parts, let’s talk about the 8 most common mistakes DIYers make during TV repair. At TVpartsToday, we’ve helped thousands of customers troubleshoot their TVs - and we’ve seen these errors time and time again.

Avoiding these mistakes will save you time, money, and a whole lot of frustration. Let’s get into it.

Would you rather watch a video on how to get started with your repair instead? Check out our YouTube video below:


❌ 1. Replacing the Wrong Board

📉 The Mistake:

Swapping out the main board when the problem is actually with the T-Con. Or replacing the power supply when it’s really a bad backlight.

âś… The Fix:

Take time to diagnose the symptoms first. For example:

  • No image but sound? Try the T-Con board.

  • Power light on but no startup? Try the main board.

  • No power at all? Start with the power supply.

🟨 TVpartsToday Tip:
Use a flashlight test to check for a faint image on the screen. This quick trick can help you determine if your backlight is out - and saves you from buying the wrong part!

Need some instruction? We have a Blog for that!


❌ 2. Buying Based on TV Model Number Only

📉 The Mistake:

Ordering a replacement board based on the TV model number alone, without verifying the part number.

âś… The Fix:

Always match the part number printed on the board itself, usually on a sticker with a barcode or QR code. Even within the same TV model, manufacturers often use different versions of internal components.

đźź© TVpartsToday Tip:
If you're unsure which part to buy, send us a photo of your original board to info@tvpartstoday.com - we’ll help you find an exact match.


❌ 3. Handling Boards Without Anti-Static Protection

📉 The Mistake:

Touching circuit boards with bare hands or working on carpeted surfaces - risking electrostatic discharge (ESD) that can silently fry components.

âś… The Fix:

  • Wear anti-static gloves or use a wrist strap

  • Work on a clean, non-carpeted surface

  • Avoid touching metal contacts or chip surfaces

🧤 Static damage isn’t a huge worry necessarily, but it is better safe than sorry! Watch the video above for more safety tips!


❌ 4. Not Inspecting Boards Before Installing

📉 The Mistake:

Skipping a visual inspection of the old board - or installing a new one without checking for visible damage or connector mismatches.

âś… The Fix:

  • Look for burn marks, swollen capacitors, or corrosion on the old board.

  • Check that the new board matches in layout and connector orientation.

  • Confirm all screws and cable positions are the same.

🟨 TVpartsToday Tip:
If a board arrives and looks different, don’t install it until confirming it’s compatible. Contact us if you're unsure - we’ll double-check for you.


❌ 5. Forgetting to Disconnect Power Completely

📉 The Mistake:

Unplugging the TV but immediately working on it - not realizing capacitors may still hold a charge.

âś… The Fix:

Always wait at least 5–10 minutes after unplugging before opening the TV. This allows time for capacitors to discharge. Also, you can hold down your TV's power button for 60-120 seconds in order to force a discharge of built up power.

Always remember: Safety first! ⚠️


❌ 6. Leaving Loose Connectors or Ribbons

📉 The Mistake:

Failing to secure ribbon cables or plugs tightly - leading to symptoms like:

  • No picture

  • Flickering screen

  • Unresponsive buttons

âś… The Fix:

  • Double-check all connections after reassembly

  • Make sure ribbon cables are fully inserted and locked into their clips

đźź© TVpartsToday Tip:
Use a flashlight to verify every cable is flush and seated. A loose LVDS or T-Con ribbon is one of the most common causes of image issues after a board swap.


❌ 7. Throwing Away the Old Board Too Soon

📉 The Mistake:

Tossing the original board before fully testing the new one - or before confirming the problem is resolved.

âś… The Fix:

Keep the old board until your repair is successful. It may still be functional or useful for comparison, or even eligible for core return credit in some cases.


❌ 8. Not Remembering Screw or Plug Placement

📉 The Mistake:

Removing screws and cables without tracking where they go - leading to lost screws, forced cables into the wrong ports, or missing connections during reassembly.

âś… The Fix:

  • Take photos at every step of disassembly

  • Keep screws in labeled containers or cups

  • Match every plug and ribbon to its original position before closing the TV

🟨 TVpartsToday Tip:
Always double check your work before powering up!


đź’¬ Final Thoughts

TV repair is rewarding - and often easier than people think - but success starts with knowing what not to do. Whether it’s ordering the wrong part, skipping a diagnosis step, or overlooking a loose cable, these common pitfalls can trip up even confident DIYers.

By following the tips above, you’ll save yourself from costly do-overs and get your TV back up and running fast. 🧑🔧

đź’¬ Need Help?

If you’re still unsure about the issue or need to replace a part, reach out to TVpartsToday. We can help you identify the exact cause of the problem and provide the right replacement part!

Would you rather watch a video? Check out our helpful Troubleshooting 101 playlist over on YouTube!
Would you rather chat with a seasoned repair expert? Head on over to our TVRepairHelp subReddit!

📦 Need help finding the right board or part?
📞 Call us at 930-212-1975 or browse our inventory online.
🛠️ DIY-friendly parts, fast shipping, and expert support – only at TVpartsToday.
