Features of the 2017 TCL Xess X2 U65X9006 65"
TCL Xess X2 U65X9006
65" 4K HDRParts
Summary
65"
4K
HDR
57.6 in
33.1 in
2.3 in
LCD
350, maximum peak of 600 nits
3000:1
Total 40 W
Android TV 6 Marshmallow
Basics: TCL Xess X2 U65X9006 specs: Technical sheet
Brand
- Brand
- TCL
- Serie
- X2
- Model
- Xess X2 U65X9006
- Other Codes
Release Date
- Year
- 2017
LCD LED
Backlight
Edge LEDEdge LED lighting illuminates the panel from the sides with worse light distribution
Technology
VAVA technology allows a greater contrast than an IPS, against losing slightly in viewing angle
Colorimetry
Quantum DotsThe quantum dots generate a greater range of colors, closer to those of the human eye
Final image
GoodGood choice for normal use, if you don't need pure blacks
Technical Details
Size (inches) and resolution
- Diagonal
- 65 inches
- Resolution
- 4K • 3840 x 2160
- Aspect ratio
- 16:09
- Pixel density
- 68 ppi
Technology
- Panel type
- LCD technology
- Subpixel type
- RGB
- Refresh rate
- 60 Hz
- Panel Manufacturer
- --
Backlight and contrast
- Backlight type
- LED
- Backlight form
- Edge LED
- Brightness
- Contast
- Light sensor
- No
Colorimetry
- Quantum Dots
- Yes • Quantum Dots QLED
- Color spaces
- Color depth
- 10 bits
HDR
- Tradename
- HDR technologies
-
- HDR10
- HLG
Crystal
- Anti-glare filter
- --
- Vision angle
-
HorizontalVertical
Processing
These features modify the images received by television via software, in many cases they create unwanted artifacts, we disable some of them, but here you have them ...
- Image processor
Response times
- Minimum time
- --
- Average time
- --
- Input lag
- 30 ms
- Gaming
- --
Technologies
Sound
- Speakers
- 20W 2x
- Power
- 40 W
- Output channels
Sound Technologies
- Technologies
-
- Dolby Digital
- Dolby Digital Plus
- DTS HD
Digital tuner:
- Terrestrial
-
- DVB-T
- DVB-T2
- DVB-S
- DVB-S2
- DVB-C
- Satelite
- Cable
-
- DVB-C
- ATSC & QAM
- No
- ISDB
- No
- DTMB
- No
Analog tuner
- NTSC
- --
- PAL
- Yes
- SECAM
- Yes
Hybrid television
- HbbTV
- No
Cable connections
- RF antenna
- Antenna (RF) 1x
- HDMI
- HDMI 2.0 3x ARC CEC MHL
- USB
- USB 2.0 1x USB 3.0 1x
- Satellite
- DVB-S DVB-S2 Satellite In (Main; F-type female) 1x
- Composite
- CI
- CI+ 1.3 1x
- Optical Audio
- Optical Audio Out 1x
- 3.5mm audio
- 3.5 mm Audio Out 1x
- Ethernet
- Ethernet RJ45 1x
Wireless connections
- Wi-Fi
- Yes • 802.11a, 802.11ac, 802.11b, 802.11g, 802.11n,
- Bluetooth
- Yes •
Content delivery
- Chromecast
- DLNA
- Wi-Fi Direct
Remote control
- Type of command
- RC64 • Remote control
- Control of multiple devices
- Yes
Others
- PVR recording
- No
- PIP
- No
Design
Image gallery
With Stand
- Dimensions
- 146.2 cm•88 cm•31 cm
- Weight
- 23 Kg
Without Stand
- Dimensions
- 146.2 cm•84.2 cm•5.8 cm
- Weight
- 22.6 Kg
- Screen shape
- Flat
- Frameless
- No
- Colors
Stand
- Removable stand
- No
- Stand shape
- --
VESA
- VESA size
- 600 x 200 mm
Others
- Single cable
- No
- Ambient mode
- No
Operating System
Operating System
- SW
- Android • Android TV 6 Marshmallow
Voice assistants
- Alexa
- Google Assistant
- Voice control
- No
Hardware
- SOC model
- ARM Cortex-A53
- RAM
- 2GB
- ROM
- 16GB
Consumption
- HbbTV
Cable connections
- Energy efficiency
- D
- Standby consumption
- 0.5 W
- Average consumption
- 120 W
- Consumption
- 170 W
Power supply
- Power supply
- 100 V - 120 V (volts)
- Wi-Fi
- Power supply frequency
- 50 Hz - 60 Hz (hertz)
Certificates
- Certificates
- ENERGY STAR, RoHS, UL/cUL
