Features of the 2023 TCL 98P745 98"
TCL 98P745
98" 4K HDRParts
Summary
98"
4K
HDR
85.4 in
48.1 in
1.8 in
LCD
-- nits
--:1
Total 30 W
Google TV
Basics: TCL 98P745 specs: Technical sheet
Brand
- Brand
- TCL
- Serie
- P745
- Model
- 98P745
- Other Codes
Release Date
- Year
- 2023
LCD LED
Backlight
Direct LEDDirect LED lighting distributes light more evenly across the panel
Technology
VAVA technology allows a greater contrast than an IPS, against losing slightly in viewing angle
Colorimetry
RGB filterThe RGB filter is found on all televisions and allows you to generate the three RGB colors
Final image
GoodGood choice for normal use, if you don't need pure blacks
Technical Details
Size (inches) and resolution
- Diagonal
- 98 inches
- Resolution
- 4K • 3840 x 2160
- Aspect ratio
- 16:9
- Pixel density
- 45 ppi
Technology
- Panel type
- LCD technology
- Subpixel type
- RGB
- Refresh rate
- 120 Hz
- Panel Manufacturer
- --
Backlight and contrast
- Backlight type
- LED
- Backlight form
- Direct LED
- Brightness
- Contast
- Light sensor
- No
Colorimetry
- Quantum Dots
- No
- Color spaces
- Color depth
- 10 bits
HDR
- Tradename
- HDR technologies
-
- Dolby Vision
- HDR10
- HDR10+
- HLG
Crystal
- Anti-glare filter
- --
- Vision angle
-
HorizontalVertical
Processing
These features modify the images received by television via software, in many cases they create unwanted artifacts, we disable some of them, but here you have them ...
- Image processor
Response times
- Minimum time
- --
- Average time
- --
- Input lag
- --
- Gaming
- ALLM , VRR
Technologies
Sound
- Speakers
- 15W 2x
- Power
- 30 W
- Output channels
- 2.1 CH
Sound Technologies
- Technologies
-
- Dolby Atmos
- Dolby Digital Plus
- Onkyo sound system
Digital tuner:
- Terrestrial
-
- DVB-T
- DVB-T2
- DVB-S
- DVB-S2
- DVB-C
- Satelite
- Cable
-
- DVB-C
- ATSC & QAM
- No
- ISDB
- No
- DTMB
- No
Analog tuner
- NTSC
- --
- PAL
- Yes
- SECAM
- Yes
Hybrid television
- HbbTV
- No
Cable connections
- RF antenna
- Antenna (RF) 1x
- HDMI
- HDMI 2.0 2x HDCP 2.3
- USB
- USB 3.0 1x
- Satellite
- DVB-S DVB-S2 Satellite In (F-type female) 1x
- Composite
- CI
- Optical Audio
- Optical Audio Out 1x
- 3.5mm audio
- 3.5 mm Audio Out 1x
- Ethernet
- Ethernet RJ45 1x
Wireless connections
- Wi-Fi
- Yes • 802.11a, 802.11ac, 802.11b, 802.11g, 802.11n,
- Bluetooth
- Yes • Bluetooth 5.0
Content delivery
- Chromecast
- Yes
- DLNA
- Yes
- Wi-Fi Direct
- Yes
Remote control
- Type of command
- --
- Control of multiple devices
Others
- PVR recording
- Yes • PVR
- PIP
- No
Design
Image gallery
With Stand
- Dimensions
- 216.8 cm•132.2 cm•24.5 cm
- Weight
- 0 Kg
Without Stand
- Dimensions
- 216.8 cm•122.2 cm•4.5 cm
- Weight
- 0 Kg
- Screen shape
- Flat
- Frameless
- No
- Colors
Stand
- Removable stand
- No
- Stand shape
- --
VESA
- VESA size
- --
Others
- Single cable
- No
- Ambient mode
- No
Operating System
Operating System
- SW
- Android • Google TV
Voice assistants
- Alexa
- Yes
- Google Assistant
- Yes
- Voice control
Hardware
- SOC model
- --
- RAM
- --
- ROM
- --
Consumption
- HbbTV
Cable connections
- Energy efficiency
- ?
- Standby consumption
- 0.5 W
- Average consumption
- --
- Consumption
- --
Power supply
- Power supply
- 100 V - 120 V (volts) 220 V - 240 V (volts)
- Wi-Fi
- Power supply frequency
- 50 Hz - 60 Hz (hertz)
Certificates
- Certificates
- RoHS, TÜV Rheinland Flicker-free Certified, TÜV Rheinland Low Blue Light Certified
