If you open a Samsung TV expecting to see a separate power supply board and main board, you may be surprised to find one large assembly handling both functions. This is not a repair complication. It is a design choice. Samsung has increasingly moved toward combination board layouts in many slim and mid-range models to reduce space, wiring, and manufacturing complexity. For DIY repairers, understanding how these combo boards work makes replacement far easier and prevents ordering mistakes.
At TVpartsToday, we regularly help customers identify the correct Samsung combo board configuration. Once you know what you are looking at, the repair process is straightforward.
Want to watch a video of some Samsung parts being replaced in a set? We've got you covered below!
Would you rather get started on your repair instead? Watch our helpful YouTube video on How to Get Started below:
Identifying a "Clipped" or "Screwed" Combo Board
Samsung televisions are designed to be thinner and more compact than ever. To accomplish this, engineers often combine the power supply and main board into a matched assembly. In many models, these are still technically two boards physically attached together and sold as a single tested unit.
Below is an example of this type of part:
The main board controls HDMI inputs, smart TV processing, audio, and video management. The power supply converts AC wall power into the various DC voltages required throughout the TV. When bundled together, they operate as a synchronized pair and are sold under one shared manufacturer part number.
Because these boards are factory-matched, separating them after purchase is not recommended. They are tested together and intended to function as one replacement assembly.
These two boards are still individually manufactured but are bundled together for simplicity and compatibility. You’ll often see them listed with a main board BN94 part number followed by “–COMBO”, or with a BN96 part number followed by “–COMBO”.
Examples of screwed or clipped together Samsung combo boards:
UN55CU7000FXZA → BN96-56840M-COMBO
UN43CU7000BXZA → BN96-56552R-COMBO
QN55Q7FAAFXZA → BN94-18652U-COMBO
TVpartsToday Tip: If your Samsung replacement arrives labeled as a combo, keep it assembled exactly as received. It has already been matched for compatibility.
Identifying a True Integrated Combo Board
In some newer Samsung designs, particularly ultra-slim or space-conscious models, the power supply and main board are fully integrated into a single non-separable circuit board. These boards handle HDMI processing, system control, and power conversion all on one piece of hardware.
Below is an example of one such part:
These integrated boards often include both HDMI ports and the AC power input directly on the same board. Unlike "clipped" or "screwed combos", there is no visible separation between power and processing sections. When replacing these, matching the exact manufacturer part number becomes even more critical because the entire power and signal system is contained in one component.
TVpartsToday Tip: If you only see one large board with both HDMI and power input connectors attached, you likely have a fully integrated combo board. Always match the exact part number on the sticker.
When the Main Board Also Handles T Con Functions
In certain Samsung models, especially entry-level or ultra-thin designs, the T Con function is built directly into the main board. In these TVs, you will not find a separate T Con board mounted near the panel.
This design reduces internal wiring and simplifies assembly. However, it also changes the repair approach. If image timing or display control issues occur, replacing the main board may be required rather than swapping a smaller T Con board.
Understanding whether the T Con is integrated prevents unnecessary searching inside the TV and helps avoid ordering the wrong component.
TVpartsToday Tip: If you cannot locate a T Con board inside your Samsung TV, it may be integrated into the main board. Confirm before ordering any replacement parts.
Why Part Numbers Matter More Than Board Numbers
One of the most common ordering mistakes involves confusing printed board numbers with manufacturer part numbers. Samsung boards often display a BN41 number printed directly on the circuit board. This is a board number used for internal manufacturing reference and does not guarantee compatibility.
The correct replacement identifier is the full manufacturer part number found on the white sticker attached to the board assembly. This number ensures the board matches your specific TV configuration, panel version, and firmware requirements.
Even TVs with the same model number can use different board revisions depending on production run or screen size variation. Matching by part number eliminates compatibility issues and reduces returns.
TVpartsToday Tip: Never order a Samsung board based solely on the printed BN41 number. Always match the complete part number from the sticker.
Combo Boards Are Easier Than They Look
While Samsung combo boards may initially appear confusing, they actually simplify the repair process. Instead of diagnosing power and main board issues separately, replacing the matched combo assembly restores both systems at once. For many no power, no picture, or startup failure issues, this streamlined approach saves time and eliminates guesswork.
Once you understand whether you are working with a clipped combo, a fully integrated board, or a main board with built-in T Con functionality, the repair becomes straightforward. Most Samsung board replacements involve disconnecting cables, transferring the new assembly, and reattaching connectors exactly as they were.
Repair with Confidence
Samsung’s combination board designs are meant to improve efficiency and slim down the TV’s footprint. For DIY repairers, the key is recognizing the configuration and ordering the correct part number.
At TVpartsToday, we help customers identify the right Samsung combo board quickly and accurately. With proper part number matching and careful installation, restoring your Samsung TV is often far easier and more cost-effective than replacing the entire set.
